50000 h

IP20

LED PANEL

Trailing edge phase dimmer This product is dimmable using a trailing edge phase dimmer.

Average lifespan in h The average lifespan of a lightbulb or light source in hours.

IP protection rating The IP protection class indicates the suitability of electrical equipment for different environmental conditions.

Light source can be replaced by a specialist The (included) light source can only be replaced by a specialist.

UGR ≤ UGR= Unified Glare Rating. Indicates the standardised value of psychological glare. The smaller the value is, the lower the glare.

Lighting family This product belongs to an SLV light family

Energy efficiency class The energy efficiency class refer to the (contained) light source.

To the technical details

PANEL 60 round

LED Indoor surface-mounted ceiling light, white, 3000 K, More

50000 h

IP20

LED PANEL

Colour:

Colour temperature:

Lumen:

Reset selection

Item no.: 1000783

TOPSELLER

RRP £251.00

Price only for commercial customers, plus VAT.

100+ in Stock

Description

The LED PANEL 60 comes with several different light and housing colours, and provides a modern and space-saving solution for an efficient type of basic lighting. The high degree of luminous flux provides a pleasant, homogeneous and glare-free lighting feeling. The electrical connection is made directly to the 230V mains voltage supply. This luminaire contains built-in LED lamps.

Trailing edge phase dimmer This product is dimmable using a trailing edge phase dimmer.

Average lifespan in h The average lifespan of a lightbulb or light source in hours.

IP protection rating The IP protection class indicates the suitability of electrical equipment for different environmental conditions.

Light source can be replaced by a specialist The (included) light source can only be replaced by a specialist.

UGR ≤ UGR= Unified Glare Rating. Indicates the standardised value of psychological glare. The smaller the value is, the lower the glare.

Lighting family This product belongs to an SLV light family

Energy efficiency class The energy efficiency class refer to the (contained) light source.

To the technical details

Technical data

Product name

PANEL 60

BIG WHITE Page

217

Colour

white

Material

Aluminium

electrical power

42 W

Luminous Flux

3150 lm

Colour temperature

3000 Kelvin

Beam angle

110 °

UGR ≤

Dimmable

Yes

Dimming technology

trailing edge

IP Code

IP20

Assembly

Surface

Assembly details

Ceiling

Height

5.5 cm

Diameter

60 cm

Primary nominal voltage

220-240V ~50/60 Hz

Secondary power / secondary voltage

1000 mA

Net weight

4.79 kg

Weighted consumption

42 kWh/1.000h

Service life

50000 h

Inrush current level

9 A

Inrush current duration

50 μs

Luminous flux

3150 lm

Manual (pdf)

Removal instructions (pdf)

Assembly drawings (pdf)

CE declaration (pdf)

Datasheet (pdf)

REACh (pdf)

FIND A DIMMER. GOOD COMBINATION.

Compatible dimmers

Berker 2883
Niko 310-0190X
LK Fuga LED Dimmer 180 Touch
Busch Jäger (6523U)
Eltako EUD 61 NPN-UC
Legrand PRO21 LED Dimmer 775659

Please note the minimum load of the dimmers used.

Because of the many different products, it is not always easy to find the best combination. Our overview should help you to find the right dimmer.

We continuously update and extend the list, so that the latest combinations and any new products are always suggested to you.
